This chapter
gives an overview of MATLAB and compares MATLAB with a scientific
calculator. The chapter gives also an overview of basic arithmetic
operations and functions as well as a short introduction to
matrices and matrix manipulation.
It is supposed that you have already installed
MATLAB on your computer. When you start MATLAB, the MATLAB desktop
opens, as shown in Fig. 1.1 (or something similar, depending on your
MATLAB version). In this first chapter we refer only to the Command
Window, where the special >> prompt appears. The other
windows have the following meaning:
![A978-1-4614-2197-9_1_Fig1_HTML.gif](A978-1-4614-2197-9_1_Fig1_HTML.gif)
Fig.
1.1
The MATLAB desktop. MATLAB release
2011b
-
The Workspace Window contains a list of variables that are in use in the working session.
-
The Command History contains the list of all commands you have typed in the command window.
-
The Current Folder window shows the list of the files contained the folder you are working on.
When the prompt >> is visible, this means
that MATLAB is waiting for a command. You can quit MATLAB at any
time in either of the following ways:
1.
Select Exit MATLAB from the desktop File
menu.
2.
Enter quit or exit after the command
window prompt >>, and press
the Enter key.
Alternatively, select File with the mouse from
the top menu bar, and then exit MATLAB.
Observe that the tab above the Workspace shows
the Current Directory Window. For example, in the Windows operating
system, the path might be as follows: C:\MATLAB\Work, indicating
that directory “Work” is a subdirectory of the main directory
“MATLAB,” which is installed in drive C. Clicking on the arrow in
the Current Directory Window shows a list of recently used paths.
Clicking on the button to the right of the window allows the user
to change the current directory. Knowing which is the current path
is fundamental: from the Command Window you have access to the file
stored in the given directory. It is, of course, possible to change
your working directory.
Before continuing our introduction to MATLAB, we
want to highlight a very useful window: the HELP Window. This
window is the most useful window for beginning MATLAB users—and for
expert users as well: select Help► PRODUCTHELP from the top bar
menu. The Help Window has most of the features you would see in any
web browser, including clickable links, a back button, and a search
engine. All MATLAB commands and functions are explained with
examples: you have simply to search for the desired word.
Now let us begin with a description of the MATLAB
language. The word “MATLAB” is the concatenation of the words
MATrix LABoratory, meaning that MATLAB is an interactive software
system for numerical computation, especially designed for
computations with matrices. Before going into the details of matrix
computations, let us first see how to use MATLAB to do simple
arithmetic operations: Type 1+1 after the >> prompt, followed
by Enter; that is, press the Enter key, as indicated by
<ENTER>
>> 1+1
<ENTER>
MATLAB gives its quick answer by displaying the
following message:
ans =
2
You can perform other arithmetic operations, such
as multiplication, subtraction, and division, and MATLAB always
returns the correct result. If such is not the case, there is
certainly something wrong with what you typed. For example, you can
try the following operations (type the operation after the >>
prompt followed by Enter):
To TYPE after prompt >> followed by
Enter
|
MATLAB answer
|
Meaning of the operation
|
---|---|---|
35*12
|
ans = 420
|
Multiplication
|
2/45
|
ans = 0.0444
|
Division
|
4−1
|
ans = 3
|
Subtraction
|
2^3
|
ans = 8
|
Exponentiation
|
Note that to type numbers such as the Avogadro’s
number 6.023 × 1023, you can either write the
expression 6.023*10^23 or you can
represent the number in
scientific notation. To
enter Avogadro’s number in scientific format, type 6.023e23,where 6.023
is the mantissa and 23 is the exponent. Mantissa and exponent must
be separated by the letter e (or E):
>> 6.023*10^23
<ENTER>
ans =
6.0230e+023
|
>> 6.023e23
<ENTER>
ans =
6.0230e+023
|
Such numbers are also defined to be floating point.
MATLAB warns you in the case of in invalid
operation or “unexpected” results. What do you think MATLAB will
show us if we type 12/0 or 0/0? Let’s try it:
To TYPE after prompt >> followed by
Enter
|
MATLAB answer
|
Meaning of the answer
|
---|---|---|
12/0
|
ans = Inf
|
You should not divide by zero, but if you
do, the result is Infinity
|
0/0
|
ans = NaN
|
Unable to find the answer, so the result is
NaN = Not a Number
|
11+
|
??? 11+
|
Error: Expression or
statement is incomplete or incorrect
|
If you want to perform this operation, you
must complete the expression with another term
|
As you can see, MATLAB is unable to “stay quiet.”
It quickly answers your commands by displaying something in the
command window. In the previous cases, the answer was a special
value such as Inf (Infinity) or NaN (Not a Number). You can use these
special values on their own, typing, for example:
>> 12/Inf
<ENTER>
ans =
0
MATLAB can be used as a scientific calculator,
combining several operations in one expression. The computation of
the expression is based on well-known mathematical rules. In
particular, some operations are performed before others, based on
precedence rules, which are given in the following table:
Precedence
|
Operator
|
---|---|
1
|
Parentheses (round brackets)
|
2
|
Exponentiation, left to right
|
3
|
Multiplication and division, left to
right
|
4
|
Addition and subtraction, left to
right
|
If you want to know the result of the operation
{2+[5*3/(7−5)2]/3} you have to type:
>>
(2+(5*3/(7-5)^2)/3) <ENTER>
ans =
3.2500
In this example, MATLAB first calculates (7−5) =
2, then it squares 2^2 = 4, then it performs the multiplication
5*3 = 15 (multiplication left to right), and then divides the
result by the previously computed result, i.e., 15/4 = 3.75. The
result in brackets is divided by 3 (3.75/3 = 1.25) and then added
to 2, giving the result. Note that in MATLAB, parentheses are
always given by round brackets.
MATLAB was developed for scientists, and for this
reason you can find built-in operations and functions that are more
advanced than the ones we have just looked at. Considering MATLAB
as a sort of scientific calculator, you can engage the “cosine
button” simply by typing:
>> cos(36)
<ENTER>
ans =
-0.1280
Other common functions are reported in the
following table. Type the operation after the >> prompt
followed by Enter:
To TYPE after prompt >> followed by
Enter
|
MATLAB answer
|
Meaning of the operation
|
---|---|---|
cos(12)
|
ans = 0.8439
|
Cosine of the element in parentheses
|
sin(12)
|
ans = −0.5366
|
Sine of the element in parentheses
|
tan(4)
|
ans = 1.1578
|
Tangent of the element in parentheses
|
exp(3)
|
ans = 20.0855
|
Exponential of the element in
parentheses
|
log(10)
|
ans = 2.3026
|
Natural logarithm of the element in
parentheses
|
log10(12)
|
ans = 1.0792
|
Base-10 logarithm of the element in
parentheses
|
We will see in the rest of the book the
possibility using many other functions. Just to introduce some:
statistical functions, interpolation functions, linear-algebraic
functions, functions for images and sound elaboration, and last but
not least, your own custom-created functions!
We conclude by giving some hints on creating and
editing command lines:
-
You can select (and edit) previous commands you have entered using the up-arrow and down-arrow keys. Remember to press Enter to execute the command.
-
MATLAB has a useful editing feature called smart recall. Just type the first few characters of the command you want to recall, e.g., type the characters lo and press the up-arrow key—this recalls the most recent command starting with lo.The result might be, for example, log(10) or log10(12).
Variables
Thus far, we have seen the use of MATLAB as a
scientific calculator. However, MATLAB is much more than a
calculator, and the main difference is the possibility to use
“variables.” In a scientific calculator we can save and recall a
single number only. In MATLAB, in contrast (as in other programming
languages), we can store and recall virtually an infinity of
different values called variables. A variable is a sort of box, having a
certain shape, a certain dimension, with a label naming it. In such
a box you can put the (virtual) item you need, for example a
number, an image, and so on.
Suppose you want to save a number representing
your age. You can create your own variable and store it by simply
typing the following command:
>> age=22
<ENTER>
age =
22
The symbol age is the variable
name (the box name), which contains the number 22. Each time you
recall (type) such a name, the content of the variable is used; in
this simple case, it is displayed. Type again the variable name:
>> age
<ENTER>
age=
22
You can define other variables, for example the
number of your friends. Just type:
>> Nfriends =
132 <ENTER>
Nfriends =
132
At this stage, you may wonder about the shape of
the box or its volume. The answer is not straightforward. However,
by typing the whos command, MATLAB
prompts all the variables currently active in the working
session:
>> whos <ENTER>
Name
|
Size
|
Bytes
|
Class
|
Attributes
|
---|---|---|---|---|
age
|
1 × 1
|
8
|
double
|
|
Nfriends
|
1 × 1
|
8
|
double
|
The whos command gives you
a list of all the variables created in the workspace together with
their characteristics. In order to understand the meaning of such
characteristics, consider the analogy between variable and box, as
presented in the following table:
Variable
|
Box
|
Visual interpretation
|
---|---|---|
Name
|
Name of the box
|
![]() |
Size
|
Number of objects you have put in (in the
previous case, just one object, i.e., 1 × 1).
|
|
Bytes
|
Total volume of the box. This is the number
of objects multiplied by the dimension of each (to store a number
you need 8 bytes)
|
|
Class
|
Type of object you can put inside the box
(in the previous case, it is a number stored with double precision)
|
|
Attributes
|
Other information
|
Note that the variables list obtained using the
command whos can readily be
seen in the Workspace Window (see Fig. 1.1).
One nice thing that MATLAB does when you create a
variable is that it automatically selects the most suitable type of
box for the variable. You need, however, to know a few simple rules
about variable names:
1.
The variable name must start with a letter.
2.
It may consist only of the letters a–z, the
digits 0–9, and the underscore (_). You cannot have a name with
spaces or others symbols (such as +, ^, *).
3.
MATLAB is case-sensitive, which means that it
distinguishes between upper- and lowercase letters. So age is different from
AgE or
Age.
Try to create the following variables by typing
them after the >> prompt followed by Enter: N-friends =
12,
$aDay =
60,
3rd_classified
= 11. What happens, and
why? MATLAB gives you the following error:
??? $aDay=60
|
Error: The input
character is not valid in MATLAB statements or
expressions.
Obviously, in these examples we didn’t follow the
aforementioned rules (use of the character—and $, beginning the
name with a number).
MATLAB has a few predefined variable names. Some
of these are presented in the following table:
To TYPE after prompt >> followed by
Enter
|
MATLAB answer
|
Value contained in the variable
|
---|---|---|
Pi
|
ans = 3.1416
|
π
|
Esp
|
ans = 2.2204e-016
|
Floating-point relative accuracy, i.e., the
distance from 1.0 to the next largest double-precision number
|
j
|
ans = 0 + 1.0000i
|
Imaginary unit, i.e., sqrt(−1), used to
enter complex numbers
|
I
|
ans = 0 + 1.0000i
|
Imaginary unit, i.e., sqrt(−1), used to
enter complex numbers
|
NaN
|
ans = NaN
|
Not a number
|
Inf
|
ans = inf
|
Infinity
|
You can redefine a variable by simply assigning
it a new value:
>> pi=12
<ENTER>
pi =
-12
>> pi
<ENTER>
pi =
-12
Once you have inserted a new value, you cannot
recall the previous one. However, in the special case of predefined
variables, you can clear the redefined variable, and the predefined
variable is restored. To clear variables you use the command
clear
followed by the variable name (or a list of them). Let’s try:
>> clear pi
<ENTER>
MATLAB doesn’t give you an answer. However, the
command has been executed. Type the pi variable again, and MATLAB will
return the value of π:
>> pi
<ENTER>
ans =
3.1416
The command clear can be followed
by the specification all, and all the
variables stored in the workspace are deleted. To test whether this
is indeed the case, type the whos command:
>> clear all
<ENTER>
>> whos
<ENTER>
>>
Note that you receive no answer from MATLAB
because there is nothing to display. At the same time, you can see
that the Workspace Window (Fig. 1.1) is empty.
With variables you can type complex expressions
and store the result. Let’s try:
>> number=13;
<ENTER>
>> a=14;
<ENTER>
>>
c=pi*((number+a/2)/10); <ENTER>
MATLAB doesn’t give an answer because you ended
the command with the semicolon (;) which prevents the value of
number
from being echoed on the screen. However, number still has the
value 13, as you can see by entering its name without a semicolon
(or looking at the Workspace Window):
>> number
<ENTER>
number =
13
>> c
<ENTER>
c =
6.2832
Thinking in a Matrix Way
Our first question about matrices is, “What is a
Matrix?” We are not talking about the film, the sequels, the comic
books, or the video games. For us, a matrix isn’t a complex
computer simulation that you have to do battle with to save
humanity. However, you can choose to continue to read the book (in
analogy to the blue pill in the film that allows you to lead your
normal life) to learn how use MATrix LABoratory to create
innovative experiments, thereby changing the world with your
discoveries.
In MATLAB, a matrix is a rectangular array of
numbers, as shown in the following Fig. 1.2.
![A978-1-4614-2197-9_1_Fig2_HTML.gif](A978-1-4614-2197-9_1_Fig2_HTML.gif)
Fig.
1.2
Matrices of various dimensions
The horizontal lines of a matrix are called rows,
and the vertical lines are called columns. The numbers in the
matrix are called entries. A matrix with m rows and n columns is
called an m ×
n matrix. A matrix one of
whose dimensions equals one is often called a vector. An m × 1
matrix (one column and m rows) is called a column vector, and a 1
× n matrix (one row and n columns) is called a row vector.
If you are familiar with the spreadsheet software
Excel, you can imagine each Excel worksheet as a matrix, with rows
and columns.
Now let’s try to define some matrices and vectors
in MATLAB. Type the following statements as written:
>> a=[3,5,7,8]
<ENTER>
a =
5 12 -2 1
>> b= [4;2;7;1]
<ENTER>
b =
4
2
7
1
>> c= [3,
53,6;12,-93,145;4,7,1;0,-21,12] <ENTER>
c =
353 6
12-93145
47 1
0 -21 12
>> whos
<ENTER>
Name SizeBytes
ClassAttributes
a1x432 double
b4x132 double
c 4x396 double
number 1x18
double
As you can see, after the command whos, each variable is
displayed together with its size expressed in rows × columns.
(Note: if you have used other variables previously, your list of
variables could be different). Note that a scalar value, like the
variable number, can be
considered a 1 × 1 matrix.
Sometimes we need to know the size of the
variables only, instead of the full list of their properties. In
this case, the function size(c) returns the
number of rows and columns of the variable c:
>> size(c)
ans =
4 3
Another useful function is length(c), which
returns the length of the vector c. If c is a matrix, the function
length
returns the number of rows only:
>>
length(c)
ans=
4
To put data into a matrix, you must type the
values within square brackets, separated by spaces or commas for different elements in a row,
while the semicolon (;) is
used to indicate the end of the row. Note that the number of
elements must be the same in each row:
>> x=[ 1 2 3; 2 5 7]
<ENTER>
x =
1 2 3
2 5 7
If you have not put the same number of elements
in each row, MATLAB displays an error:
>> x = [2 3; 2 5
7];
??? Error using ==>
vertcat
CAT arguments dimensions are
not consistent.
As you can see, MATLAB is not a wizard who tries
putting the missing element in the right place. MATLAB does not
know whether you want to put the element 2 and 3 in the first and
second columns or in the second and third columns
respectively.
You can use a matrix or a vector to implement
another variable. For example, type in the following
statements:
>> x = [3 2 1];
<ENTER>
>> y = [6,7,8];
<ENTER>
>> z1 = [x -y];
<ENTER>
>> z2 = [x; -y];
<ENTER>
Can you work out what z1 and z2 will look
like before displaying them? In the following table we present
other examples showing how to use variables already implemented to
create new variables:
Mathematical representation
|
MATLAB (type after the prompt >>
followed by Enter)
|
Dimension
|
---|---|---|
![]() |
M=[3,12,pi];
|
1 × 3 Row vector
|
![]() |
N=[3,12,pi;
8,9,10];
|
2 × 3 Matrix
|
Or equivalently, if you have already
inserted M:
|
||
N=[M; 8,9,10];
|
||
![]() |
P=[4;2;−1]
|
3 × 1 Column vector
|
![]() |
Q=[4, −4;2, −2;−1, 1];
|
3 × 2 Matrix
|
Or equivalently, if you have already
inserted P:
|
||
Q=[P;−P];
|
If you do not specify any variable content (i.e.,
any values inside the square brackets), MATLAB creates a variable
of size zero with no value, or more precisely, a matrix of
dimension 0 × 0 with no value in it.
>> y = [ ];
<ENTER>
>> whos y
<ENTER>
NameSizeBytesClassAttributes
y 0x00double
The Workspace Browser in the desktop provides a
handy visual representation of the workspace. By clicking a
variable in the Workspace Browser, we open the Array Editor, which
can be used to view and change values.
The entry that lies in the ith row and the jth column of a matrix is typically
referred to as the (i,j), or (i,j)th entry of the matrix. For example,
the (3,2) entry of matrix Q in the table above is 1. In
mathematical format, it is usually written as Q3,2,
while in MATLAB you can access to the matrix entries in this
way:
>> Q(3,2)
<ENTER>
ans =
1
Note the use of parentheses. For indexing you use
parentheses, whereas to define a matrix, you use square brackets;
otherwise, you get an error:
>>Q[2,3]
??? Q[2,3]
|
Error: Unbalanced or
unexpected parenthesis or bracket.
In the following table you can find other
examples:
Mathematical representation
|
MATLAB (type after the prompt >>
followed by Enter)
|
---|---|
![]() |
>>Q(3,1)
ans=
-1
|
![]() |
>> N(2,2)
ans=
9
|
![]() |
>> M(1,3)
ans=
3.1416
|
![]() |
>> N(2,1)
ans=
2
|
If P and M are two vectors, it is possible to
refer to their entries by referencing only their single dimension,
i.e., you can type M(3) instead of M(1,3), and N(2) instead of
N(2,1).
If you refer to an element in a nonexistent
position, MATLAB gives you an alert:
>> Q(3,3)
<ENTER>
??? Index exceeds matrix
dimensions.
What happens if you want to address more than one
element at time? This is possible in MATLAB using a vector (or a
matrix) in the indexing place to express the selected rows or
columns:
>> Q([1,3],2)
<ENTER>
ans =
-4
1
How many values do you expect MATLAB to display
when you type Q([1,3],[1,2]) ? Two or Four? Let’s try:
>>
Q([1,3],[1,2]) <ENTER>
ans =
4 -4
-1 1
The answer is four, because MATLAB shows the
values in the positions given by each combination of the specified
rows and columns, i.e., Q11, Q12,
Q31, Q32.
Now suppose you have a large matrix from which
you want to extract elements going from the ith row to the jth row
in the second column. MATLAB offers a very efficient way to this,
namely the colon (:)
operator. Before seeing how it works, let us generate a new
matrix:
>> x=[1 2 3; 4 5 6; 7 8
9; 10 11 12; 13 14 15] <ENTER>
x =
1 2 3
4 5 6
7 8 9
10 11 12
13 14 15
Now type:
>> i=2;
j=4;<ENTER>
>>
x(i:j,2)<ENTER>
ans =
5
8
11
Note that more than one command has been typed on
the first line. This can be done by separating commands with a
semicolon. In addition, note that MATLAB displays exactly the
values from the second row to the fourth row in the second columns.
This is equivalent to:
>> x([2 3 4],2)
<ENTER>
ans =
5
8
11
As a matter of fact, using the colon operator is
equivalent to generating a vector going from a given value to
another one, possible using a prescribed increment (step). The rule
is:
Start:Step:Stop
Type the following commands:
To TYPE after prompt >> followed by
Enter
|
MATLAB answer
|
Meaning of the operation
|
---|---|---|
2:5:25
|
ans =
2 7 12 17 22
|
Generate a vector going from 2 to 25
incremented by 5. Note that 22 + 5 = 27, which is greater than
25. MATLAB will generate numbers until it reaches or exceeds the
Stop value (i.e., 25)
|
i:j
|
ans =
2 3 4
|
Generate a vector going from 2 to 4. Here
the step value is not specified, and MATLAB uses the default value
1
|
10:−3:−5
|
ans =
10 7 4 1 -2 -5
|
Generate a vector going from 10 to −5,
increasing the first value by −5. This is equivalent to generating
a vector of decreasing values
|
You now have three equivalent ways of accessing
the third-row entries of x:
>> x(3,[1 2
3])<ENTER>
ans =
7 8 9
>>
x(3,1:3)<ENTER>
ans =
7 8 9
>>
x(3,:)<ENTER>
ans =
7 8 9
In the last case, you do not need to specify the
start and stop values when you use the colon operator. MATLAB
assumes that you mean the entire row. Analogously, if you need the
first column only, you can type either x([1,2,3,4,5],1) or
x([1:5],1)
or x(:,1);
By using the colon operator together with the
empty array, we are able to delete entire rows or entire columns.
For example, to delete the entire second column of x and then its
third and fourth rows, type:
>> x(:,2) = [
]<ENTER>
x =
1 3
4 6
7 9
10 12
13 15
>> x([3,4],:) =[
] <ENTER>
x =
1 3
4 6
13 15
Note that you cannot delete a single entry in a
matrix because that would lead to an ambiguity in its dimensions.
So a statement like x(1,2)=[ ] returns an error:
>> x(1,2)=[
]
??? Subscripted assignment
dimension mismatch.
We conclude this paragraph by mentioning a way to
create a matrix using indexing. In contrast to other computer
languages, in MATLAB we do not need to declare a variable
(i.e., tell to MATLAB what type of variable, how large it is, etc.)
before using it. MATLAB creates the variable on the fly. So if you
want to insert the response time to the stimulus number 10, you can
simply type:
>>
AnsTime(10)=1.34
AnsTime =
0 0 0 0 0 0 0 00
1.3400
MATLAB automatically creates the variable called
AnsTime and put the number you have entered in position 10. The
unspecified values are filled with zeros by default.
Operations
There are operations that can be applied to
modify the contents of a matrix without changing the number of
elements. These operations are matrix addition, scalar multiplication, and transposition. These form the basic
techniques for dealing with matrices, as displayed in the following
table:
Operation
|
Definition
|
Math example
|
Matlab example
|
---|---|---|---|
Addition (subtraction)
|
The result of A + B or (A−B) is calculated entrywise, i.e., the
element Bi,j is added to (subtracted from) the element
in Ai,j
|
![]() |
>>A=[1,5;2,3];
>>B=[2,3;4,1];
>>A+B
ans =
3 8
6 4
>> A-B
ans =
-1 2
-2 2
|
Scalar multiplication
|
The multiplication of a scalar (= number)
s by a matrix
C is obtained by multiplying
every entry of C by
s
|
![]() |
>>C=[3,2;4,1];
>>s=4;
>>s*C
ans =
12 8
16 4
|
Transposition
|
The transpose of an m × n matrix
D is an n × m matrix
denoted by D T
obtained by turning rows into columns and columns into rows
|
![]() |
>>
D=[2,12,2;8,9,10];
>> D’
ans =
3 8
12 9
2 10
|
Multiplication of a matrix by another matrix is
more complicated. Multiplication of two matrices is well
defined only if the number of columns of the left-hand matrix is
the same as the number of rows of the right-hand matrix. Matrix
multiplication may seem complex, and perhaps you will not use it
very often. However, it turns out to be useful when one of the
matrices is a vector, so we give you the following
definition:
If A is an
m × n matrix and B is an n × p matrix, then their matrix product AB is the m × p matrix whose entries are given by the
following equation.
The equation means that each element of the ith row of A is multiplied successively by each
element of the jth column of B. In Fig. 1.3 you can see a visual
interpretation of the previous equation.
![$$ {(AB)}_{i,j}={\displaystyle \sum _{r=1}^{n}{A}_{i,r}{B}_{r,j}}$$](A978-1-4614-2197-9_1_Chapter_TeX2GIF_Equa.gif)
![A978-1-4614-2197-9_1_Fig3_HTML.gif](A978-1-4614-2197-9_1_Fig3_HTML.gif)
Fig.
1.3
Visual interpretation of matrix
product
We reiterate that a matrix product can be
performed only if the number of columns in the first matrix
(A) is equal to the number of
rows of the second matrix (B). For example, using the matrices
entered in the previous table, it is not possible to perform the
product DC (try to verify
this with MATLAB):
>> D*C
??? Error using ==>
mtimes
Inner matrix dimensions must
agree.
However, you can compute the product CD. The
result is a matrix having the same number of rows as the first
matrix (C) and the same
number of columns as the second matrix (D). We see, then, that in general, for
two matrices CD ≠
DC, and indeed, one of these
products might not even be defined. But even if C and D are square matrices, it is generally
the case that CD ≠
DC:
>> C*D
<ENTER>
ans =
22 54 26
16 57 18
An element-by-element operation similar to matrix
summation is also available in MATLAB. Let’s say that we want to
multiply the elements of A in
position i,j by the elements of B in the same i,j position using the
element-by-element
operators, as shown in the following table:
Description
|
MATLAB operator
|
Example
|
---|---|---|
Element-by-element Multiplication
|
.*
|
>> A.*B
ans=
2 15
8 3
|
Element-by-element Right division
|
./
|
>> A./B
ans =
0.5000 1.6667
0.5000 3.0000
|
Element-by-element Left division
|
.\
|
>> A.\B
ans =
2.0000 0.6000
2.0000 0.3333
|
Element-by-element Exponentiation
|
.^
|
>> A.^B
ans =
1 125
16 3
|
For those who are familiar with matrix equations,
MATLAB has a huge number of other possible operations. Here are
some of the basic functions: The inverse function inv(A), the determinant function
det(A), the eigenvalue
function eig(A), the
singular value decomposition function svd(A), the LU factorization
lu(A).
Summary
-
MATLAB can be thought of as a scientific calculator: you can perform operations from simple to complex, simply by typing them into the command line of the command window; operations are calculated immediately.
-
The six arithmetic operators for scalars are + − * \ / and ˆ. They operate according to rules of precedence. Parentheses have the highest precedence.
-
To store numbers or operation results you need variables.
-
Variable names consists only of letters, digits, and underscores, and must start with a letter. MATLAB interprets uppercase and lowercase as different letters (e.g., AgE is different from age).
-
The command whos lists the variable in the workspace. To delete variables use clear followed by the name of variables, or alternatively, clear all to clear every variable.
-
MATLAB refers to all variables as matrices:
-
An N × M matrix is an array having N rows and M columns.
-
A vector can be a 1 × N matrix (row vector) or an N × 1 matrix (column vector)
-
A scalar is a 1 × 1 matrix
-
-
Vectors and matrices are entered in square brackets. Elements are separated by spaces or commas. Rows are separated by semicolons.
-
An element of a matrix is referred to by a pair of numbers in parentheses indicating its position. An element of a vector can be referenced using simply a number. A range of elements can be referred to using vectors instead numbers in parentheses.
-
The Colon operator is equivalent to generating a vector going from one value to another, possibly using a specified increment (step): start:step:stop
-
Pay attention when using Matrix operations especially to the dimensions of the matrices involved.
-
The basic matrix operations are addition (+), scalar multiplication (*), and transposition (‘).
-
Element-by-element operations between matrices of the same dimension can be carried out using the operators ./.\.* and.^.
Exercises
1.
Evaluate the following expressions:
Mathematical expression
|
Solution (to type after prompt >>
followed by Enter)
|
Result
|
---|---|---|
![]() |
2*4/12*2^2
|
ans = 2.6667
|
![]() |
2*3+5/2−7.5
|
ans = 1
|
![]() |
sqrt(16)
|
ans = 4
|
![]() |
(13*3)/(12−4)
|
ans = 4.875
|
![]() |
((2*pi+4)−2*sin(pi/4))/(12−3)
|
ans = 0.9854
|
![]() |
Try by yourself. The result must be the
same
|
ans = 4.2500
|
![]() |
Try by yourself. The result must be the
same
|
ans = 4.7958
|
2.
Create in MATLAB the following variables:
Mathematical expression
|
Solutions (to type after prompt >>
followed by Enter)
|
---|---|
![]() |
Mat1=[3, 4.56, 8, 7; 12, 2, 1, 3; pi, 34,
2, 3];
|
![]() |
Mat2=[1, 0, 0; 0, 0, 0; 0, 0, 0; 0, 0,
3];
|
or
|
|
Mat2=1;
Mat2(4,3)=3;
|
|
![]() |
Mat3=[2,4,6,8,10,12,14;
3,6,9,12,15,18,21];
|
or
|
|
Mat3=2:2:14;
Mat3(2,:)=3:3:21;
|
3.
c is a variable containing the second and the
third elements of the third row of Mat1.
b is a variable containing the first and second
elements of the second row of Mat3.
Create a matrix called bbcc with b on top of
c.
Use the first column of Mat1 and the transpose of
the last row of Mat2 to create a new matrix called nice. Multiply
the result by the third element in the first row of Mat3.
SubMat1 is a matrix obtained from the second and
fourth columns of Mat3.
SubMat2 is a matrix obtained from the first and
last columns of Mat3.
NewMat is a 2x4 matrix obtained by using SubMat1
in the first two columns, and SubMat2 in the second two
columns.
Solutions:
To type after prompt >> followed by
Enter
|
Display by MATLAB
|
---|---|
c=Mat1(1,2:3)
or
c=Mat1(1,[2,3])
|
c =
4.5600 8.0000
|
b=Mat3(2,1:2)
|
b =
3 6
|
REsuLT=(b+c)*4
|
REsuLT =
30.2400 56.0000
|
bbcc=[b;c]
|
bbcc =
3.0000 6.0000
4.5600 8.0000
|
nice=[Mat1(:,1),
(Mat2(4,:))’]*Mat3(1,3)
|
nice =
18.0000 0
72.0000 0
18.8496 18.0000
|
SubMat1=Mat3(:,[2,4])
|
SubMat1 =
4 8
6 12
|
Try by yourself
|
SubMat1 =
2 14
3 21
|
Try by yourself
|
NewMat =
4 8 2 14
6 12 3 21
|
4.
Calculate the sum of b and c and multiply the
result by 4. Put the result in the matrix REsuLT.
Create a matrix Mol obtained from
element-by-element multiplication between SubMat1 and
SubMat2.
Change the element in position (2,2) of Mol to
5;
To type after prompt >> followed by
Enter
|
Display by MATLAB
|
---|---|
REsuLT=(b+c)*4
|
REsuLT =
30.2400 56.0000
|
Mol=SubMat1.*SubMat2
|
Mol =
8 112
18 252
|
PAY ATTENTION: MATLAB can also compute the
product Mol = SubMat1*SubMat2. However, that is not the
element-by-element product
|
|
Mol(2,2) = 5
|
Mol =
8 112
18 5
|
A Brick for an Experiment
In this section of the book we illustrate, step
by step, a MATLAB program implementing a behavioral experiment
together with the graphical interface for running the program and
the statistical analysis for analyzing the data. The experiment we
are implementing is a classic experiment in audiovisual perception
by Sekuler et al. (1997). The
effect showed by these authors is one of the most compelling
examples of interaction between audition and vision. It can be
observed by comparing the post coincidence trajectories of two
moving objects. The objects are perceived as bouncing off each
other or as streaming through each other according to whether a
sound is presented (or not) when the objects overlap during the
motion (Sekuler et al. 1997;
Watanabe and Shimojo 2001; Remijn
et al. 2004; Kawabe and Miura
2006; Kawachi and Gyoba
2006; Zhou et al. 2007; Grassi and Casco 2009, 2010; Grove
and Sakurai 2009). The effect is
based on a motion display originally proposed by Metzger
(1934). Metzger’s display shows two
identical objects (e.g., two discs) that move along the azimuth
with uniform rectilinear motion and opposite directions: discs
start their motion, overlap and stop at the other disc’s starting
point with uniform rectilinear motion. This simple two-dimensional
display is a complex inverse optics problem for the visual system
(Marr 1982). The display is equally
representative of two different events in the real
three-dimensional world. In both events the two objects are placed
at different depths so that the retinal images of both have
identical size. In one event, the objects start their motion,
overlap (i.e., one object occludes the other), then stream past one
another. In the other possible event, in contrast, after the
occlusion, the objects reverse their motion and return to their
original starting positions. In brief, the motion of the discs is
bistable because both the streaming and bouncing percepts are
compatible with the proximal stimulus. However, the streaming
percept is usually predominant if the motion display is silent,
whereas the bouncing is predominant when the sound is presented. We
strongly suggest that the reader read the cited paper to have a
clearer idea about the experiment we are going to implement in the
“brick” section.
Here, we implement the original experiment by
Sekuler et al. (1997). The
experiment is a 2 (motion type) by 2 (sound condition) experiment.
In the experiment, a disc’s motion can be continuous, or it can
stop for a certain number of frames when the discs overlap. In
addition, the discs’ motion can be accompanied (or not) by a brief
sound that is presented when the discs overlap. The subject’s task
is to report whether s/he perceived the discs as streaming or as
bouncing. Usually, in this type of experiment, the experimenter
records the proportion of bounce responses as a function of the
various experimental conditions (the number of streaming responses
is, of course, the reciprocal of the number of bounce
responses).
The experiment by Sekuler et al. (1997) is a classic “fixed stimuli” experiment. In
other words, we know before the subject participates in the
experiment what and how many stimuli we are going to
present.1 This is
an advantage, because we can prepare many things in advance. For
example, a wise thing to do in such cases is to write an event
table, i.e., a table in which we write the exact experimental
condition we are going to present to the subject trial after trial.
In the event table all events will be represented in numbers.
In this chapter we limit ourselves to writing few
variables that will turn out to be useful later. First of all,
let’s write one variable containing the two factors we are
manipulating in the experiment. We will symbolize each
factor/condition in numbers.
>> conditions = [1, 1;
1, 2; 2, 1; 2, 2];
if you visualize the content of this variable, it
looks like this:
>>
conditions
conditions =
1 1
1 2
2 1
2 2
The left column codes as a number the video
display we are presenting (e.g., 1 = continuous motion; 2 =
discontinuous motion), the right column codes as a number the
sound associated with the display (1 = no sound; 2 = sound).
However, usually in psychological experiments stimuli are presented
more than once, i.e., they are presented with a certain number of
repetitions (say, 20 times each).
>> repetitions =
20;
we can now begin to write the event table:
>> EventTable =
[];
>> EventTable =
[EventTable; conditions];
>> EventTable =
[EventTable; conditions];
>> EventTable =
[EventTable; conditions];
You should repeat the command EventTable =
[EventTable;
conditions]; 20 times (i.e., the number of repetitions) in
order to obtain the complete event table. In a later chapter we
will show how to generate repetitive commands automatically.
Now let’s add to the left of the EventTable a new
column with the trial number (note the use of the apostrophe, which
transposes the array we are creating, so that EventTable becomes a
matrix of a few columns but several rows, one row for each trial of
the experiment):
>> TotalNumberOfTrials
= length(EventTable(:, 1));
>> TrialNumber =
(1:TotalNumberOfTrials)’;
>> EventTable =
[TrialNumber, EventTable];
Now let’s look at the content of the table
matrix. At trial number 12, for example, we know that we are going
to present the display 2 (the discontinuous motion) together with
the sound (i.e., 2). At trial number 37, we will present the
display 1 (the continuous motion) and no sound (i.e., 1), and so
on. However, in the current experiment, as in the majority of
experiments in psychology, we want the stimuli to be randomized
within the block of trials the subject performs. In this way, we
avoid possible unwanted effects such as the serial effects that
could arise if we were using, for example, a fixed sequence of
trials. We can do this by shuffling the trial sequence by means of
randperm,
which is a MATLAB function that generates a random permutation of
integers from 1 to n, i.e., the input the user has to pass to the
function. (Note that we will transpose the output of the
randperm
function so that we have an array with one column and several
rows.) Now we substitute the trial sequence column by the shuffled
trial sequence column:
>> RandomTrialSequence
= randperm(TotalNumberOfTrials)’;
>> EventTable(:, 1) =
RandomTrialSequence;
Now let’s sort the EventTable content by
the shuffled trial number in the first column:
>> EventTable =
sortrows(EventTable, 1);
If you now echo in the command window the content
of the EventTable matrix, you
will see that the stimuli presentation list is now nicely
randomized.
A part of the commands we have shown will be
included in a script that automatically generates the event table
in the desired form. This will be shown in Chap.
3.
References
Marr D (1982) Vision: a
computational investigation into the human representation and
processing of visual information. W. H. Freeman, New York
Metzger W (1934)
Beobachtungen über phänomenale Identität. Psychol Forsch
19:1–60CrossRef
Suggested Readings
Some of the concepts
illustrated in this chapter can be found, in an extended way, in
the following books:
Gilat A (2008) MATLAB: an
introduction with applications. Wiley, Mahwah, N.J.
Hunt BR, Lipsaman RL et al
(2006) A guide to MATLAB: for beginners and experienced users, 2nd
edn. Cambridge University Press, Cambridge, United
KingdomCrossRef
Kattan PI (2008) MATLAB for
beginners: a gentle approach, Revised edn. Lulu.com, Raleigh, NC,
United States
Rosenbaum DA (2007) MATLAB
for behavioral scientists. Lawrence Erlbaum Associates, Hoboken,
N.J.
Footnotes
1
This is not the case of adaptive psychophysical
procedures in which the stimuli presented are selected trial by
trial as a function of the subject’s response.
